Products Description
Ni95Al5 thermal spray wire is a commonly used spray material with many excellent properties and is suitable for various high-temperature and corrosion-resistant coating applications. It is mainly composed of nickel (Ni) and aluminum (Al), of which the nickel content accounts for about 95% and the aluminum content accounts for about 5%. This chemical composition makes Ni95Al5 alloy have good high temperature resistance and oxidation resistance, forming a dense oxide layer in high temperature environment, effectively protecting the base material from oxidative corrosion.
The diameter of Ni95Al5 thermal spray wire is usually between 0.8mm and 3.2mm, and the tensile strength can reach 350MPa to 550MPa, which ensures that the spray coating has good mechanical properties and strength. Its melting point is approximately 1260°C (2300°F), giving it excellent stability under high temperature conditions.
In addition, Ni95Al5 alloy also has good thermal conductivity and certain corrosion resistance, although its corrosion resistance is slightly inferior to other alloys such as Inconel 625 relative to corrosive media in some specific environments. However, the coating hardness of Ni95Al5 alloy is usually between 200HV and 300HV, which has better wear resistance and scratch resistance.
Thermal spray wire series: Inconel 625, 45CT, Ni95Al5, Monel 400, Monel K500, Hastelloy C276, Cr20Ni80, pure zinc wire
Specification
Item | Inconel 625 | Ni95Al5 | 45CT | Monel 400 | Monel K500 | HC-276 | Cr20Ni80 |
C | ≤0.05 | ≤0.02 | 0.01-0.1 | ≤0.04 | ≤0.25 | ≤0.02 | ≤0.08 |
Mn | ≤0.4 | ≤0.2 | ≤0.2 | 2.5-3.5 | ≤1.5 | ≤1.0 | ≤0.06 |
P | ≤0.01 | ≤0.01 | ≤0.01 | ≤0.01 | ≤0.01 | ≤0.01 | ≤0.02 |
S | ≤0.01 | ≤0.01 | ≤0.01 | ≤0.01 | ≤0.01 | ≤0.01 | ≤0.01 |
Si | ≤0.15 | ≤0.2 | ≤0.2 | ≤0.15 | ≤0.5 | ≤0.08 | 0.75-1.6 |
Cr | 21.5-23 | ≤0.2 | 42-46 | -- | -- | 14.5-16 | 20-23 |
Ni | rest | rest | rest | 65-67 | rest | rest | rest |
Cu | -- | -- | -- | rest | 27-33 | -- | -- |
Mo | 8.5-10 | -- | -- | -- | -- | 15-17 | -- |
Ti | ≤0.4 | 0.4-1 | 0.3-1 | 2.0-3 | 0.35-0.85 | -- | -- |
Al | ≤0.4 | 4-5 | -- | ≤0.5 | 2.3-3.15 | -- | -- |
Fe | ≤1.0 | -- | ≤0.5 | ≤1.0 | ≤1.0 | 4.0-7.0 | -- |
Nb | 3.5-4.15 | -- | -- | -- | -- | -- | ≤1.0 |
| Co | -- | -- | -- | -- | -- | -- | -- |
V | -- | -- | -- | -- | -- | ≤0.35 | -- |
W | -- | -- | -- | -- | -- | 3.0-4.5 | -- |
Impurities | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.5 |
For more details, pls directly contact us.
Alloy composition and properties
Ni95Al5 is a nickel-based alloy whose composition mainly contains 95% nickel (Ni) and 5% aluminum (Al). This alloy exhibits a range of excellent physical and chemical properties due to its unique composition ratio. Nickel is a metal with a face-centered cubic (FCC) structure and has good ductility and toughness, while the addition of aluminum significantly improves the alloy's anti-oxidation and anti-corrosion properties.
Thermal spray technology
Thermal spraying is a surface engineering technology that melts or softens the coating material and sprays it onto the substrate surface at high speed to form a layer of surface coating with special functions. Thermal spray technology is widely used to improve the wear resistance, corrosion resistance, heat resistance and sealing of parts.
Application of Ni95Al5 thermal spray wire
Anti-oxidation and anti-corrosion coating: Since the Ni95Al5 alloy contains a high proportion of aluminum, the coating formed has extremely strong anti-oxidation and anti-corrosion properties and is suitable for industrial parts in extreme environments.
Repair and remanufacturing: Thermal spray technology can be used to repair damaged parts, and Ni95Al5 thermal spray wire can be used to restore part dimensions or improve surface properties.
Anti-adhesion coating: In the chemical and food processing industries, Ni95Al5 thermal spray wire can be used to create anti-adhesion surfaces, reduce material adhesion, and improve production efficiency.
Electronic packaging: In the field of microelectronic packaging, Ni95Al5 thermal spray wire can be used to make packaging materials with good thermal conductivity.
Aerospace field: Due to its high-temperature properties, Ni95Al5 thermal spray wire can be used for surface treatment of aerospace components to improve their performance and life in high-temperature environments.
Preparation of thermal spray wire
The preparation of Ni95Al5 thermal spray wire usually involves alloy smelting, wire extrusion and subsequent processing. To ensure the quality and performance of sprayed wires, precise control of the alloy composition and microstructure of the wire is required.
In conclusion
Ni95Al5 thermal spray wire has broad application prospects in industrial applications due to its excellent physical and chemical properties. With the continuous advancement of thermal spray technology, Ni95Al5 thermal spray wire is expected to be applied in more fields, bringing more possibilities to industrial production.
