Name:InconelbarMaterial:Ni Cr FeNickel(Min):72%Density:8.47 G/cm3Melting Point:1,370-1,415℃Tensile Strength:≥550 MPaYield Strength:≥240 MPaElongation:≥30%Sureface:Bright,Oxided
0
Products Description
Inconel alloy bars play an important role in the chemical industry. This alloy is a high-temperature, corrosion-resistant material composed of nickel, chromium and other alloying elements.
There are various corrosive media and high temperature environments in the chemical industry, so the requirements for materials are very strict. Inconel alloy rods have excellent corrosion resistance and can resist the erosion of acids, alkalis, salts and other corrosive media. It can also maintain stable performance in high-temperature environments and is not prone to oxidation, sulfidation, chlorination and other reactions. Therefore, in the corrosive environment of the chemical industry, Inconel alloy rods are widely used in the manufacture of key components such as pipes, vessels, reactors and heat exchange equipment.
In addition, Inconel alloy rods also have good mechanical properties and high strength. It can withstand the stress under high pressure and high temperature conditions generated in the chemical process, and has good fatigue resistance and creep resistance. This makes it excellent in applications such as machine parts, valves, pumps and pressure vessels in the chemical industry.
Parameter:
Item | Inconel 600 | Inconel 601 | Inconel 617 | Inconel 625 | Inconel 690 | Inconel 718 | Inconel X750 | Inconel 825 |
C | ≤0.15 | ≤0.1 | 0.05-0.15 | ≤0.08 | ≤0.05 | ≤0.08 | ≤0.08 | ≤0.05 |
Mn | ≤1 | ≤1.5 | ≤0.5 | ≤0.35 | ≤0.5 | ≤0.35 | ≤1 | ≤1 |
Fe | 6-10 | rest | ≤3 | rest | 7-11 | rest | 5-9 | ≥22 |
P | ≤0.015 | ≤0.02 | ≤0.015 | -- | -- | -- | -- | -- |
S | ≤0.015 | ≤0.015 | ≤0.015 | ≤0.015 | ≤0.015 | ≤0.01 | ≤0.01 | ≤0.03 |
Si | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.35 | ≤0.5 | ≤0.35 | ≤0.5 | ≤0.5 |
Cu | ≤0.5 | ≤1 | -- | ≤0.3 | ≤0.5 | ≤0.3 | ≤0.5 | 1.5-3 |
Ni | ≥72 | 58-63 | ≥44.5 | 50-55 | ≥58 | 50-55 | ≥70 | 38-46 |
Co | -- | -- | 10-15 | ≤10 | -- | ≤1 | ≤1 | -- |
Al | -- | 1-1.7 | 0.8-1.5 | ≤0.8 | -- | 0.2-0.8 | 0.4-1 | ≤0.2 |
Ti | -- | -- | ≤0.6 | ≤1.15 | -- | -- | 2.25-2.75 | 0.6-1.2 |
Cr | 14-17 | 21-25 | 20-24 | 17-21 | 27-31 | 17-21 | 14-17 | 19.5-23.5 |
Nb+Ta | -- | -- | -- | 4.75-5.5 | -- | 4.75-5.5 | 0.7-1.2 | -- |
Mo | -- | -- | 8-10 | 2.8-3.3 | -- | 2.8-3.3 | -- | 2.5-3.5 |
B | -- | -- | ≤0.006 | -- | -- | -- | -- | -- |
Shape | Size (mm) |
Wire | 0.5-7.50 |
Rod/Bar | 8.0-200 |
Strip | (0.5-2.5)*(5-180) |
Tube/Pipe | Customized |
Sheet/Plate | Customized |
For more details, pls directly contact us.
Characteristic:
Corrosion resistance: Inconel alloy rods have excellent resistance to a variety of corrosive media, including acid, alkali and salt water. This makes it ideal for equipment and components with strict corrosion resistance requirements in the chemical industry.
High temperature resistance: Inconel alloy rods can maintain high strength and corrosion resistance in high temperature environments. This makes it suitable for use in process equipment such as high-temperature reactors, furnaces and pipelines.
Oxidation resistance: Inconel alloy rods have good oxidation resistance and can work stably for a long time in oxidizing environments, reducing equipment loss and maintenance requirements.
Advantage:
Durability and Reliability: The corrosion resistance and high temperature performance of Inconel alloy rods extend the service life of equipment and reduce the frequency of repairs and replacements. This makes chemical industry equipment more reliable and reduces the risk and cost of production downtime.
Versatility: Inconel alloy rods can be customized to specific needs, with a variety of adaptable compositions and heat treatments. It can meet the material performance requirements of different chemical processes and is widely used in various equipment and components such as reactors, heat exchangers, pipes, valves, etc.
Safety: Due to its corrosion resistance and high temperature properties, Inconel alloy rods can prevent safety issues such as corrosion, leakage and equipment failure that may occur in the chemical industry, improving workplace safety and operator safety.
Specific applications:
Specific applications of Inconel alloy rods in the chemical industry include:
Chemical reactor: Inconel alloy rods can be used to manufacture corrosion-resistant and high-temperature-resistant chemical reactors. They are able to withstand corrosive media and high temperature conditions during chemical reactions.
Pipes and Valves: Inconel alloy rods are commonly used in the manufacture of piping systems and valves in the chemical industry. They maintain stability and reliability in corrosive media and high temperature environments.
Heat exchangers: Inconel alloy rods are used in the chemical industry to manufacture heat exchangers for efficient heat transfer and corrosion resistance. This material is able to withstand the high temperatures and corrosive components of the heat transfer medium.
Q&A:
Q: What is the price of Inconel alloy rods?
Answer: Inconel alloy rods are relatively expensive due to their rare metal composition and high performance properties. Specific prices will vary based on alloy composition, specifications, market supply and demand and other factors.
Q: Does Inconel alloy bar have good machinability?
Answer: Yes, Inconel alloy bars have good processability and can be used for forging, heat treatment, cold working and welding.
Q: What are the advantages of Inconel alloy rods compared with other materials?
Answer: Compared with other common metal materials (such as stainless steel), Inconel alloy rods have better corrosion resistance, high temperature strength and oxidation resistance. It is able to work in harsher chemical environments and high temperature conditions, so it is more common in the chemical industry.
Q: What are the other application areas of Inconel alloy rods?
Answer: In addition to the chemical industry, Inconel alloy rods are also widely used in aerospace, energy, automobiles, marine engineering and other fields.
