Name:InconelbarMaterial:Ni Cr FeNickel(Min):72%Density:8.47 G/cm3Melting Point:1,370-1,415℃Tensile Strength:≥550 MPaYield Strength:≥240 MPaElongation:≥30%Sureface:Bright,Oxided
0
Products Description
Inconel alloy rods have a wide range of applications in the energy industry. Composed of nickel, chromium and other alloying elements, this alloy provides excellent high-temperature properties and corrosion resistance.
The energy industry has harsh working environments such as high temperature, corrosion and pressure, which places extremely high demands on materials. Inconel alloy rods can maintain stable mechanical properties and structural integrity under high temperature conditions, and have excellent resistance to oxidation, sulfurization and chlorination. Therefore, in the energy industry, Inconel alloy rods are widely used in key equipment and components in the fields of oil, gas and chemical processes, such as refining units, petrochemical plants, gas turbines and nuclear energy facilities.
In addition, Inconel alloy rods also have excellent corrosion resistance and can resist the erosion of acids, alkalis, salts and other corrosive media. Inconel alloy bar performs well in applications such as chemical processing, corrosive media transportation and marine environments in the energy industry, extending the service life of equipment and pipelines.
Parameter:
High temperature components, such as turbine blades, guide vanes, turbine disks, high pressure compressor disks, machine manufacturing and combustion chambers used in the manufacture of aviation, naval and industrial gas turbines.
Item | Inconel 600 | Inconel 601 | Inconel 617 | Inconel 625 | Inconel 690 | Inconel 718 | Inconel X750 | Inconel 825 |
C | ≤0.15 | ≤0.1 | 0.05-0.15 | ≤0.08 | ≤0.05 | ≤0.08 | ≤0.08 | ≤0.05 |
Mn | ≤1 | ≤1.5 | ≤0.5 | ≤0.35 | ≤0.5 | ≤0.35 | ≤1 | ≤1 |
Fe | 6-10 | rest | ≤3 | rest | 7-11 | rest | 5-9 | ≥22 |
P | ≤0.015 | ≤0.02 | ≤0.015 | -- | -- | -- | -- | -- |
S | ≤0.015 | ≤0.015 | ≤0.015 | ≤0.015 | ≤0.015 | ≤0.01 | ≤0.01 | ≤0.03 |
Si | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.35 | ≤0.5 | ≤0.35 | ≤0.5 | ≤0.5 |
Cu | ≤0.5 | ≤1 | -- | ≤0.3 | ≤0.5 | ≤0.3 | ≤0.5 | 1.5-3 |
Ni | ≥72 | 58-63 | ≥44.5 | 50-55 | ≥58 | 50-55 | ≥70 | 38-46 |
Co | -- | -- | 10-15 | ≤10 | -- | ≤1 | ≤1 | -- |
Al | -- | 1-1.7 | 0.8-1.5 | ≤0.8 | -- | 0.2-0.8 | 0.4-1 | ≤0.2 |
Ti | -- | -- | ≤0.6 | ≤1.15 | -- | -- | 2.25-2.75 | 0.6-1.2 |
Cr | 14-17 | 21-25 | 20-24 | 17-21 | 27-31 | 17-21 | 14-17 | 19.5-23.5 |
Nb+Ta | -- | -- | -- | 4.75-5.5 | -- | 4.75-5.5 | 0.7-1.2 | -- |
Mo | -- | -- | 8-10 | 2.8-3.3 | -- | 2.8-3.3 | -- | 2.5-3.5 |
B | -- | -- | ≤0.006 | -- | -- | -- | -- | -- |
Shape | Size (mm) |
Wire | 0.5-7.50 |
Rod/Bar | 8.0-200 |
Strip | (0.5-2.5)*(5-180) |
Tube/Pipe | Customized |
Sheet/Plate | Customized |
For more details, pls directly contact us.
Characteristic:
High temperature resistance: Inconel alloy rods can maintain high strength and corrosion resistance in high temperature environments. This makes it suitable for high-temperature equipment and components in the energy industry, such as gas turbines, combustors and heat exchangers.
Corrosion resistance: Inconel alloy rods have excellent resistance to a variety of corrosive media, including acidic, alkaline and high-temperature gases. This makes it ideal for equipment and pipes in the energy industry where corrosion resistance is critical.
Oxidation resistance: Inconel alloy rods have good oxidation resistance and can work stably for a long time under high temperature conditions, reducing oxidation and corrosion of equipment.
Advantage:
High performance: Inconel alloy rods can maintain good performance in high temperatures and corrosive environments, extending the service life of equipment and reducing the frequency of repairs and replacements. This makes energy industry equipment more reliable and increases the efficiency and stability of energy production.
Lightweight design: Inconel alloy rods have a lower density than other high-temperature alloys, allowing for lightweight design. This has important implications in the energy industry for improving equipment performance, reducing weight and reducing energy consumption.
Versatility: Inconel alloy rods can be customized to specific needs, with a variety of adaptable compositions and heat treatments. It can meet the material performance requirements of different energy applications, such as burners, oil extraction equipment and nuclear power plant components.
Specific applications:
Specific applications of Inconel alloy bars in the energy industry include:
Gas turbine: Inconel alloy rods are commonly used to manufacture key components such as blades, combustion chambers and nozzles in gas turbines. They are able to withstand high temperatures and high-velocity airflows while having good corrosion resistance.
Nuclear power plant equipment: Inconel alloy rods are widely used in fuel elements, reactor pressure vessels, nuclear fuel processing equipment and other components in nuclear power plants. They are able to withstand extreme environmental conditions such as high temperature, high pressure and radiation.
Oil Extraction Equipment: Inconel alloy rods are used in oil extraction equipment to manufacture corrosion-resistant and high-temperature components, such as oil well casing, valves and pipes. These equipment are often exposed to acidic and high-temperature oil well environments and require excellent corrosion resistance.
Q&A:
Q: What is the difference between Inconel alloy rods and other high temperature alloys?
Answer: Compared with other high-temperature alloys (such as molybdenum alloys and titanium alloys), Inconel alloy rods have better corrosion resistance and oxidation resistance. It maintains high strength and stability under high temperatures and corrosive environments.
Q: What is the manufacturing process of Inconel alloy rods?
Answer: Inconel alloy rods are usually manufactured using melting and solidification processes, such as vacuum arc melting and continuous casting. First, the alloy raw materials are heated to a high temperature, and then the molten alloy liquid is converted into a solid rod through the process of melting and solidification.
Q: What are the limitations of Inconel alloy rods?
Answer: Although Inconel alloy rods have many advantages, they also have some limitations. First, its manufacturing cost is relatively high because the alloy composition contains expensive alloying elements. Secondly, due to its good corrosion resistance, Inconel alloy rods may be replaced by more economical materials in some special applications. In addition, Inconel alloy rods are difficult to process and require the use of appropriate processing methods and equipment to achieve the desired shape and size.
