Name:InconelbarMaterial:Ni Cr FeNickel(Min):72%Density:8.47 G/cm3Melting Point:1,370-1,415℃Tensile Strength:≥550 MPaYield Strength:≥240 MPaElongation:≥30%Sureface:Bright,Oxided
0
Products Description
Inconel alloy rods are widely used in the field of medical devices. Made of nickel, chromium and other alloying elements, this alloy has excellent resistance to high temperatures, corrosion and biocompatibility.
The field of medical devices places very stringent requirements on materials as they need to come into contact with human tissue and body fluids and maintain stable performance during complex surgeries and treatments. Inconel alloy rods have good biocompatibility and will not cause allergic reactions or toxic reactions, so they are widely used in the manufacture of various medical devices, such as implants, surgical instruments and dental equipment.
In addition, Inconel alloy rods also have excellent corrosion resistance and can withstand corrosive media such as body fluids and disinfectants. It can remain stable during high-temperature sterilization and disinfection processes and will not undergo oxidation, sulfurization, chlorination and other reactions, thus ensuring the long-term service life of medical devices.
In addition, the mechanical properties and strength of Inconel alloy rods are also very excellent. It can withstand the stress and load during the use of medical devices and has good fatigue resistance and creep resistance. As a result, Inconel alloy rods provide reliable structural support and performance in critical applications such as surgical instruments, implants and stents.
Parameter:
Item | Inconel 600 | Inconel 601 | Inconel 617 | Inconel 625 | Inconel 690 | Inconel 718 | Inconel X750 | Inconel 825 |
C | ≤0.15 | ≤0.1 | 0.05-0.15 | ≤0.08 | ≤0.05 | ≤0.08 | ≤0.08 | ≤0.05 |
Mn | ≤1 | ≤1.5 | ≤0.5 | ≤0.35 | ≤0.5 | ≤0.35 | ≤1 | ≤1 |
Fe | 6-10 | rest | ≤3 | rest | 7-11 | rest | 5-9 | ≥22 |
P | ≤0.015 | ≤0.02 | ≤0.015 | -- | -- | -- | -- | -- |
S | ≤0.015 | ≤0.015 | ≤0.015 | ≤0.015 | ≤0.015 | ≤0.01 | ≤0.01 | ≤0.03 |
Si | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.35 | ≤0.5 | ≤0.35 | ≤0.5 | ≤0.5 |
Cu | ≤0.5 | ≤1 | -- | ≤0.3 | ≤0.5 | ≤0.3 | ≤0.5 | 1.5-3 |
Ni | ≥72 | 58-63 | ≥44.5 | 50-55 | ≥58 | 50-55 | ≥70 | 38-46 |
Co | -- | -- | 10-15 | ≤10 | -- | ≤1 | ≤1 | -- |
Al | -- | 1-1.7 | 0.8-1.5 | ≤0.8 | -- | 0.2-0.8 | 0.4-1 | ≤0.2 |
Ti | -- | -- | ≤0.6 | ≤1.15 | -- | -- | 2.25-2.75 | 0.6-1.2 |
Cr | 14-17 | 21-25 | 20-24 | 17-21 | 27-31 | 17-21 | 14-17 | 19.5-23.5 |
Nb+Ta | -- | -- | -- | 4.75-5.5 | -- | 4.75-5.5 | 0.7-1.2 | -- |
Mo | -- | -- | 8-10 | 2.8-3.3 | -- | 2.8-3.3 | -- | 2.5-3.5 |
B | -- | -- | ≤0.006 | -- | -- | -- | -- | -- |
Shape | Size (mm) |
Wire | 0.5-7.50 |
Rod/Bar | 8.0-200 |
Strip | (0.5-2.5)*(5-180) |
Tube/Pipe | Customized |
Sheet/Plate | Customized |
For more details, pls directly contact us.
Characteristic:
Biocompatibility: Inconel alloy rods have good biocompatibility and are compatible with human tissues, reducing immune reactions and rejection reactions caused by the material.
Corrosion resistance: Inconel alloy rods have excellent resistance to body fluids and corrosive media in living organisms, and can work stably in the body to reduce material failure caused by corrosion.
Strength and toughness: Inconel alloy rods have high strength and toughness and can withstand the loading and stress during the use of medical devices.
Advantage:
High temperature resistance: Inconel alloy rods can maintain stable performance during high temperature sterilization and high temperature processing, and are suitable for medical devices that require high temperature sterilization or high temperature processing.
Wear resistance: Inconel alloy rods have good wear resistance and can resist material wear caused by physical wear and friction, extending the service life of medical devices.
Processability: Inconel alloy rods have good processability and can be formed and manufactured through various processing methods (such as milling, drilling and welding, etc.) to meet the complex shape and size requirements of medical devices.
Specific applications:
Specific applications of Inconel alloy rods in the field of medical devices include:
Orthopedic implants: Inconel alloy rods are often used to manufacture orthopedic implants, such as bone screws, bone plates and bone hooks. They have excellent biocompatibility and corrosion resistance and provide strength support and stability in human bones.
Heart stents: Inconel alloy rods are widely used in the manufacture of heart stents for the treatment of coronary artery disease. They provide support and restore blood flow within blood vessels.
Medical tools: Inconel alloy rods are also used to make various medical tools, such as scalpels, tweezers, and pliers. They offer high strength and durability to meet the demands of surgical procedures.
Q&A:
Q: How does Inconel alloy rod compare with stainless steel in medical devices?
Answer: Compared with stainless steel, Inconel alloy rods have better corrosion resistance and high temperature resistance. Inconel alloy rods are more suitable for use in some medical device applications that require corrosion resistance and high temperature sterilization.
Q: Are Inconel alloy rods magnetic?
A: Inconel alloy rod is generally non-magnetic, which makes it advantageous in certain medical device applications. However, the specific alloy composition and processing conditions may have an impact on its magnetic properties and therefore need to be selected based on requirements in specific applications.
Q: What is the price of Inconel alloy rods?
Answer: Inconel alloy rods are more expensive than other common metal materials. Its price is affected by factors such as alloy composition, size and market supply and demand. Specific prices can be consulted with the supplier or manufacturer for accurate information.
