Productname: inconel bar Grade: Nickel Base Alloy Ni (Min): 72% Size: Customized Density：8.1-8.4g/cm³ Melting Point：1350-1410℃ Tensile Strength：500-1200Mpa Yield Strength：200-1000Mpa
0
Products Description
Inconel alloy rod is a high-performance alloy material composed of nickel, chromium and other alloy elements. It has excellent high temperature performance, corrosion resistance and mechanical properties, so it is widely used in many fields.
First of all, Inconel alloy rods play an important role in the aerospace field. Because equipment such as aerospace engines need to withstand extremely high temperatures and pressures during operation, materials are required to have excellent heat resistance and corrosion resistance.
In addition, Inconel alloy rods are also widely used in the chemical and energy industries. Chemical processes often involve high temperatures and corrosive media, and the energy sector is increasingly demanding high-temperature and high-pressure equipment.
In short, Inconel alloy rods are widely used in various fields due to their excellent properties. Its high temperature performance, corrosion resistance and mechanical properties make it ideal for critical components that need to withstand extreme conditions, making important contributions to the development and progress of various fields.
Parameter：
Item | Inconel 600 | Inconel 601 | Inconel 617 | Inconel 625 | Inconel 690 | Inconel 718 | Inconel X750 | Inconel 825 |
C | ≤0.15 | ≤0.1 | 0.05-0.15 | ≤0.08 | ≤0.05 | ≤0.08 | ≤0.08 | ≤0.05 |
Mn | ≤1 | ≤1.5 | ≤0.5 | ≤0.35 | ≤0.5 | ≤0.35 | ≤1 | ≤1 |
Fe | 6-10 | rest | ≤3 | rest | 7-11 | rest | 5-9 | ≥22 |
P | ≤0.015 | ≤0.02 | ≤0.015 | -- | -- | -- | -- | -- |
S | ≤0.015 | ≤0.015 | ≤0.015 | ≤0.015 | ≤0.015 | ≤0.01 | ≤0.01 | ≤0.03 |
Si | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.35 | ≤0.5 | ≤0.35 | ≤0.5 | ≤0.5 |
Cu | ≤0.5 | ≤1 | -- | ≤0.3 | ≤0.5 | ≤0.3 | ≤0.5 | 1.5-3 |
Ni | ≥72 | 58-63 | ≥44.5 | 50-55 | ≥58 | 50-55 | ≥70 | 38-46 |
Co | -- | -- | 10-15 | ≤10 | -- | ≤1 | ≤1 | -- |
Al | -- | 1-1.7 | 0.8-1.5 | ≤0.8 | -- | 0.2-0.8 | 0.4-1 | ≤0.2 |
Ti | -- | -- | ≤0.6 | ≤1.15 | -- | -- | 2.25-2.75 | 0.6-1.2 |
Cr | 14-17 | 21-25 | 20-24 | 17-21 | 27-31 | 17-21 | 14-17 | 19.5-23.5 |
Nb+Ta | -- | -- | -- | 4.75-5.5 | -- | 4.75-5.5 | 0.7-1.2 | -- |
Mo | -- | -- | 8-10 | 2.8-3.3 | -- | 2.8-3.3 | -- | 2.5-3.5 |
B | -- | -- | ≤0.006 | -- | -- | -- | -- | -- |
Shape | Size (mm) |
Wire | 0.5-7.50 |
Rod/Bar | 8.0-200 |
Strip | (0.5-2.5)*(5-180) |
Tube/Pipe | Customized |
Sheet/Plate | Customized |
For more details, pls directly contact us.
Feature：
High temperature resistance: Inconel alloy rods can maintain excellent mechanical properties and corrosion resistance at extremely high temperatures.
Corrosion resistance: Inconel alloy rods have excellent corrosion resistance against a variety of corrosive media, including acids, alkalis, oxides and salt water.
Oxidation resistance: Inconel alloy rods can resist oxidation and ablation in high-temperature oxidizing environments.
High strength: Inconel alloy rods have good mechanical properties and can maintain high strength and rigidity under high temperature conditions.
Applications:
Inconel alloy rods have a wide range of applications in the following fields:
Petrochemical industry: used to manufacture high-temperature furnace tubes, stoves, heaters and reactors and other equipment, used to handle high temperature, high pressure and corrosive media.
Aerospace: Used in the manufacture of high-temperature components such as turbine engine components, combustion chambers, nozzles, turbine blades and gas turbines.
Nuclear industry: used in fuel rods in nuclear reactors, nuclear reactor pressure vessels and nuclear waste treatment equipment.
Chemical Processing: Used to manufacture chemical reactors, catalyst supports and high-temperature chemical processing equipment.
Q&A:
Q: What is the difference between Inconel alloy rods and Incoloy alloy rods?
Answer: Inconel alloy and Incoloy alloy are both high-temperature alloys, but their compositions are slightly different. Inconel alloy is mainly composed of nickel, chromium and iron, while Incoloy alloy has higher iron and molybdenum content. In addition, Inconel alloy has better corrosion resistance in high temperature and corrosive environments, while Incoloy alloy is more suitable for some high temperature and highly corrosive environments.
Q: How difficult is it to process Inconel alloy bars?
Answer: Inconel alloy rods are challenging to process due to their high hardness and heat resistance. Its high hardness can cause cutting difficulties and tool wear. In addition, Inconel alloy also has high ductility and is prone to problems such as cold welding and poor cutting of chips. Therefore, when processing Inconel alloy bars, it is usually necessary to select a suitable cutting coating and appropriate cutting parameters to ensure processing quality and tool life.
Q: What are the specific applications of Inconel alloy rods in the aviation field?
Answer: Inconel alloy rods have various applications in the aerospace field. It is commonly used in the manufacture of various components of aerospace engines, such as turbine blades, combustion chambers, nozzles, turbine disks and turbine disk blades. Since Inconel alloy has excellent high temperature resistance and corrosion resistance and can maintain stable performance in high temperature and high pressure working environments, it is very suitable for use in components such as aerospace engines that require high temperature strength and corrosion resistance.
