Name:InconelbarMaterial:Ni Cr FeNickel(Min):72%Density:8.47 G/cm3Melting Point:1,370-1,415℃Tensile Strength:≥550 MPaYield Strength:≥240 MPaElongation:≥30%Sureface:Bright,Oxided
0
Products Description
Inconel alloy rods are widely used in the field of pressure vessels. This alloy is composed of nickel, chromium and other alloying elements and provides excellent high temperature performance, corrosion resistance and mechanical properties.
Pressure vessels are widely used in the petrochemical industry, chemical industry and energy fields, carrying high-pressure and high-temperature media. Inconel alloy rods can maintain excellent performance under extreme working conditions and have excellent resistance to oxidation, sulfurization and chlorination. Therefore, in the manufacturing of pressure vessels, Inconel alloy rods are widely used in key locations such as linings, bushings and key components to ensure the safety and reliability of the vessel.
In addition, Inconel alloy rods also have excellent corrosion resistance and can resist the erosion of acids, alkalis, salts and other corrosive media. In the chemical treatment, pickling and high-salinity environment of pressure vessels, Inconel alloy rods perform well and can effectively extend the service life of the vessel.
At the same time, Inconel alloy rods have excellent mechanical properties and high strength. It can withstand the high pressure and stress during the working process of the pressure vessel, and has good fatigue resistance and creep resistance. This makes it ideal for manufacturing critical components such as pressure vessel panels, flanges and connections.
Parameter:
Item | Inconel 600 | Inconel 601 | Inconel 617 | Inconel 625 | Inconel 690 | Inconel 718 | Inconel X750 | Inconel 825 |
C | ≤0.15 | ≤0.1 | 0.05-0.15 | ≤0.08 | ≤0.05 | ≤0.08 | ≤0.08 | ≤0.05 |
Mn | ≤1 | ≤1.5 | ≤0.5 | ≤0.35 | ≤0.5 | ≤0.35 | ≤1 | ≤1 |
Fe | 6-10 | rest | ≤3 | rest | 7-11 | rest | 5-9 | ≥22 |
P | ≤0.015 | ≤0.02 | ≤0.015 | -- | -- | -- | -- | -- |
S | ≤0.015 | ≤0.015 | ≤0.015 | ≤0.015 | ≤0.015 | ≤0.01 | ≤0.01 | ≤0.03 |
Si | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.35 | ≤0.5 | ≤0.35 | ≤0.5 | ≤0.5 |
Cu | ≤0.5 | ≤1 | -- | ≤0.3 | ≤0.5 | ≤0.3 | ≤0.5 | 1.5-3 |
Ni | ≥72 | 58-63 | ≥44.5 | 50-55 | ≥58 | 50-55 | ≥70 | 38-46 |
Co | -- | -- | 10-15 | ≤10 | -- | ≤1 | ≤1 | -- |
Al | -- | 1-1.7 | 0.8-1.5 | ≤0.8 | -- | 0.2-0.8 | 0.4-1 | ≤0.2 |
Ti | -- | -- | ≤0.6 | ≤1.15 | -- | -- | 2.25-2.75 | 0.6-1.2 |
Cr | 14-17 | 21-25 | 20-24 | 17-21 | 27-31 | 17-21 | 14-17 | 19.5-23.5 |
Nb+Ta | -- | -- | -- | 4.75-5.5 | -- | 4.75-5.5 | 0.7-1.2 | -- |
Mo | -- | -- | 8-10 | 2.8-3.3 | -- | 2.8-3.3 | -- | 2.5-3.5 |
B | -- | -- | ≤0.006 | -- | -- | -- | -- | -- |
Shape | Size (mm) |
Wire | 0.5-7.50 |
Rod/Bar | 8.0-200 |
Strip | (0.5-2.5)*(5-180) |
Tube/Pipe | Customized |
Sheet/Plate | Customized |
For more details, pls directly contact us.
Characteristic:
High temperature resistance: Inconel alloy rods can maintain good mechanical properties and corrosion resistance in high temperature environments, and are suitable for pressure vessels that withstand high temperatures and high pressures.
Corrosion resistance: Inconel alloy rods have excellent resistance to various corrosive media (such as acidic solutions, salt water and oxides, etc.), which can extend the service life of pressure vessels.
High strength: Inconel alloy rods have high strength and toughness and can withstand high stress and vibration under the working conditions of pressure vessels.
Advantage:
High temperature resistance: Inconel alloy rods can maintain stable performance in high temperature environments and are not easy to deform or lose strength. They are suitable for manufacturing high temperature pressure vessels, such as petrochemical equipment and nuclear energy equipment.
Corrosion resistance: Inconel alloy rods have excellent corrosion resistance and can resist the erosion of corrosive media such as acid, alkali and salt water, allowing pressure vessels to be used for a long time in harsh working environments.
Fatigue resistance: Inconel alloy rods have good fatigue resistance and can maintain stable performance under long-term high stress and vibration environments, extending the service life of pressure vessels.
Specific applications:
Specific applications of Inconel alloy rods in the field of pressure vessels include:
Petrochemical equipment: Inconel alloy rods are often used to manufacture pressure vessels in high temperature and corrosive environments in petrochemical equipment, such as reactors, heat exchangers and distillation towers.
Nuclear energy equipment: Inconel alloy rods are widely used in pressure vessels in nuclear energy equipment, such as fuel elements and coolant systems in nuclear reactors, to provide good high temperature and corrosion properties.
Chemical process equipment: Inconel alloy rods can also be used to manufacture pressure vessels in chemical process equipment, such as chemical reactors, corrosive media storage tanks and piping systems, to meet special corrosion resistance and high temperature requirements.
Q&A:
Q: How does Inconel alloy bar compare with stainless steel in pressure vessel applications?
Answer: Compared with stainless steel, Inconel alloy rods have higher high temperature resistance and corrosion resistance. Therefore, Inconel alloy rods are more suitable for use in the manufacturing of pressure vessels that need to withstand high temperatures and corrosive environments, such as chemical and nuclear energy equipment.
Q: How is the processability of Inconel alloy rods?
Answer: Inconel alloy rods have relatively poor processability and may encounter some challenges during processing due to their high strength and high temperature resistance. For the processing of Inconel alloy rods, special cutting tools and process parameters are usually required to ensure high precision and high quality processing results.
Q: What is the price of Inconel alloy rods?
Answer: Inconel alloy bars have a higher price than general steel and stainless steel. This is because the alloy composition and manufacturing process of Inconel alloy are relatively complex, resulting in high production costs. Therefore, material selection needs to take both cost and performance requirements into consideration and be evaluated based on specific application needs.
