10Mm 20Mm 30Mm Diameter Nickel Alloy Tubes Price Per Kg Astm Nickel Seamless Pipe

Productname：pure nickel tube Grade：nickel Ni (Min)：99.6% Size：1mm~30mm Resistance (μΩ.m)：stable Ultimate Strength (≥ MPa)：830 Elongation (≥ %)：30% Melting Point：370-1425 ℃

Inquire Now

WHAT ARE YOU LOOKING FOR?

This field is required

Total quantity you need

This field is required

Email format error

Due to email instability, you might miss our correspondence. Please provide your phone number for alternative contact.

This field is required

Telephone information is wrong!

Send Message

Product Detail


Products Description

Customized pure nickel 200 seamless pipe ni 200 nickel tube

Nickel 200 (UNS N02200) Nickel 201 (UNS N02201)

Alloy 200/201 is extremely resistance to caustic alkalies up to and including the molten state. The extra-low carbon content of Alloy 200/201 gives virtual immunity to intergranular attack above about 315°C. The presence of chlorates must be kept to aminimum, as they accelerate the rate of attack.
Good resistance to corrosion in acids and alkalis and is most useful under reducing conditions.

Grade	Ni+Co	Cu	Si	Mn	C	Mg	S	P	Fe
N4	99.9	≤0.015	≤0.03	≤0.002	≤0.01	≤0.01	≤0.001	≤0.001	≤0.04
N6	99.5	0.10	0.10	0.05	0.10	0.10	0.005	0.002	0.10
Ni201	≥99.9	≤0.25	≤0.35	≤0.35	≤0.02	/	≤0.01	/	≤0.40
Ni200	≥99.6	≤0.25	≤0.35	≤0.35	≤0.15	/	≤0.01	/	≤0.40

CHEMICAL COMPOSITION
Alloy	Ni+Co %	Mn %	Fe %	Si %	Cu %	C %	S %
Nickel 201	Min 99.2	Max 0.35	Max 0.4	Max 0.35	Max 0.25	Max 0.02	Max 0.01
Nickel 200	Min 99	Max 0.35	Max 0.4	Max 0.35	Max 0.25	Max 0.15	Max 0.01

Physical Data
Density	Specific Heat	Electrical Resistivity	Melting Point	Thermal Conductivity	Mean Coeff Thermal Expansion
8.89g/cm3	0.109(456 J/kg.℃)	0.096×10-6ohm.m	1435-1446℃	70.2 W/m-K	13.3×10-6m/m.℃

Application:

* Manufacture and handling of sodium hydroxide, particularly at temperature above 300C.
* Production of viscose rayon. Manufacture of soap.
* Analine hydrochloride production and in the chlorination of aliphatic hydrocarbons such as benzene, methane and ethane.
* Manufacture of vinyl chloride monomer.
* Reactors and vessels in which fluorine is generated and reacted with hydrocarbons.
* Processes using caustic alkalines
* Food Processing
* Synthethic Fiber Production

For more details, pls directly contact us.
