Productname: inconel pipe Grade: Nickel Base Alloy Ni (Min): 72% Size: Customized Density：8.1-8.4g/cm³ Melting Point：1350-1410℃ Tensile Strength：500-1200Mpa Yield Strength：200-1000Mpa Elongation：15-45%
0
Products Description
Inconel pipes have a wide range of applications in the chemical industry. Since chemical processes often involve harsh conditions such as high temperatures, corrosive media, and oxidizing environments, traditional materials often fail to meet the requirements, and Inconel pipes are favored for their excellent performance and corrosion resistance.
First, Inconel pipes have excellent corrosion resistance. In the chemical industry, highly corrosive media such as acids, alkalis, oxidants and corrosive gases are often involved. Inconel pipes can resist the erosion of these corrosive media and maintain the integrity and reliability of the pipeline. It has good anti-oxidation and anti-sulfurization properties and is not easily affected by chemical reaction products, thereby extending the service life of the pipe.
Secondly, Inconel pipes have excellent high temperature strength and oxidation resistance. In the chemical industry, many processes require high-temperature conditions, and even involve high-temperature oxidation environments. Inconel pipes can maintain high mechanical strength and stability at high temperatures and are not easily deformed and broken. At the same time, its anti-oxidation properties enable it to operate stably in high-temperature oxidizing atmospheres for a long time and is less likely to produce oxide layers and corrosion.
In addition, Inconel pipes have good processability and welding properties. It can meet the design and manufacturing needs of complex piping systems and adapt to various shapes of pipe fittings and connection requirements. Inconel pipes can be subjected to various processing operations such as cutting, bending, flaring and welding to facilitate pipe installation and repair in the chemical industry.
To sum up, Inconel pipes play an important role in the chemical industry. Its corrosion resistance, high-temperature strength and oxidation resistance make it an ideal pipe material for corrosion-resistant and high-temperature environments in chemical processes. By using Inconel pipes, you can ensure the safe operation of chemical industry processes, improve system reliability, and meet the chemical industry's strict requirements for material performance.
Parameter：
Item | Inconel 600 | Inconel 601 | Inconel 617 | Inconel 625 | Inconel 690 | Inconel 718 | Inconel X750 | Inconel 825 |
C | ≤0.15 | ≤0.1 | 0.05-0.15 | ≤0.08 | ≤0.05 | ≤0.08 | ≤0.08 | ≤0.05 |
Mn | ≤1 | ≤1.5 | ≤0.5 | ≤0.35 | ≤0.5 | ≤0.35 | ≤1 | ≤1 |
Fe | 6-10 | rest | ≤3 | rest | 7-11 | rest | 5-9 | ≥22 |
P | ≤0.015 | ≤0.02 | ≤0.015 | -- | -- | -- | -- | -- |
S | ≤0.015 | ≤0.015 | ≤0.015 | ≤0.015 | ≤0.015 | ≤0.01 | ≤0.01 | ≤0.03 |
Si | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.35 | ≤0.5 | ≤0.35 | ≤0.5 | ≤0.5 |
Cu | ≤0.5 | ≤1 | -- | ≤0.3 | ≤0.5 | ≤0.3 | ≤0.5 | 1.5-3 |
Ni | ≥72 | 58-63 | ≥44.5 | 50-55 | ≥58 | 50-55 | ≥70 | 38-46 |
Co | -- | -- | 10-15 | ≤10 | -- | ≤1 | ≤1 | -- |
Al | -- | 1-1.7 | 0.8-1.5 | ≤0.8 | -- | 0.2-0.8 | 0.4-1 | ≤0.2 |
Ti | -- | -- | ≤0.6 | ≤1.15 | -- | -- | 2.25-2.75 | 0.6-1.2 |
Cr | 14-17 | 21-25 | 20-24 | 17-21 | 27-31 | 17-21 | 14-17 | 19.5-23.5 |
Nb+Ta | -- | -- | -- | 4.75-5.5 | -- | 4.75-5.5 | 0.7-1.2 | -- |
Mo | -- | -- | 8-10 | 2.8-3.3 | -- | 2.8-3.3 | -- | 2.5-3.5 |
B | -- | -- | ≤0.006 | -- | -- | -- | -- | -- |
Shape | Size (mm) |
Wire | 0.5-7.50 |
Rod/Bar | 8.0-200 |
Strip | (0.5-2.5)*(5-180) |
Tube/Pipe | Customized |
Sheet/Plate | Customized |
For more details, pls directly contact us.
Features：
Corrosion resistance: Inconel pipes have excellent corrosion resistance and can resist strong acids, strong alkali, salt solutions and other corrosive media in the chemical industry, maintaining the integrity and durability of the pipeline.
High-temperature strength: Inconel pipes have excellent high-temperature strength and can withstand stress and thermal cycles in high-temperature environments in the chemical industry, ensuring the stability and reliability of the pipeline system.
Oxidation resistance: Inconel pipes have good antioxidant properties and can resist oxidation and thermal corrosion under high temperature conditions. They are suitable for high-temperature equipment and pipeline systems in the chemical industry.
Mechanical properties: Inconel pipes have excellent mechanical properties, including high strength, toughness and wear resistance, and can withstand mechanical stress and wear in the chemical industry.
Specific applications:
Chemical reactors: Inconel pipes are widely used in reactor systems in the chemical industry, including high-temperature and high-pressure chemical reactors and catalyst systems, to meet the requirements for corrosion resistance and high-temperature strength.
Acid and alkali storage tanks: Inconel pipes are used in acid and alkali storage tanks and containers in the chemical industry. They can withstand corrosive media such as strong acids and alkalis while maintaining the structural integrity and safety of the storage tanks.
Pipeline transportation system: Inconel pipes are used in pipeline transportation systems in the chemical industry, including pipelines for transporting acid and alkali solutions, organic solvents and corrosive media, to ensure the safety and reliability of the transportation process.
Refining and petrochemical processes: Inconel pipes play an important role in refining and petrochemical processes and are used in high-temperature and high-pressure reactors, fractionation towers, heating furnaces and steam recovery systems to meet the needs for corrosion resistance and high-temperature strength.
Catalyst system: Inconel pipes are widely used in catalyst systems in the chemical industry, including catalyst carriers, catalyst beds and catalytic reactors, etc., to provide high temperature resistance and corrosion resistance and promote catalytic reactions.
Q&A：
What are the disadvantages of Inconel tubes?
Inconel pipes are relatively expensive and difficult to process.
What are the options for Inconel tube sizes and specifications?
Inconel pipe sizes and specifications can be customized to specific application needs and are available in a variety of diameters, wall thicknesses and lengths.
Can Inconel pipe be used in high pressure applications?
Yes, Inconel pipe has high strength and pressure resistance and is suitable for high pressure applications.
