Productname: Inconel plate Grade: Nickel chrome Ni (Min): 58% Size: Customized Size Resistance (μΩ.m): 1.5 Ultimate Strength (≥ MPa): 830 Elongation (≥ %): 30% Melting Point:1435-1446°C
0
Products Description
Inconel sheets play an important role in the chemical industry. Due to its excellent corrosion resistance and high temperature stability, Inconel sheets are widely used in chemical equipment, reactors, evaporators, heat transfers and other corrosion-resistant equipment and pipelines.
In the chemical industry, many processes involve the treatment of strong acids, strong alkali, salt solutions and other corrosive media, so the corrosion resistance of materials is extremely high. With its excellent corrosion resistance, Inconel plates can operate stably for a long time in acidic, alkaline and oxidizing environments. It can resist the corrosion of acidic media, resist the erosion of salt solutions and chemical substances, and ensure the safe operation of chemical equipment.
In addition, there are high-temperature and high-pressure working conditions in the chemical industry, which require materials with excellent high-temperature stability and strength. Inconel sheets can maintain their strength and stability in high temperature environments, withstand stress and loads under high pressure and high temperatures, and can be used for a long time in harsh working environments.
Parameter:
Item | 600 | 601 | 617 | 625 | 690 | 718 | X750 | 825 |
C | ≤0.15 | ≤0.1 | 0.05-0.15 | ≤1.0 | ≤0.05 | ≤0.08 | ≤0.08 | ≤0.05 |
Mn | ≤1 | ≤1.5 | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.35 | ≤1 | ≤1 |
Fe | 6-10 | rest | ≤3 | ≤5.0 | 7-11 | rest | 5-9 | ≥22 |
P | ≤0.015 | ≤0.02 | ≤0.015 | ≤0.015 | -- | -- | -- | -- |
S | ≤0.015 | ≤0.015 | ≤0.015 | ≤0.015 | ≤0.015 | ≤0.01 | ≤0.01 | ≤0.03 |
Si | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.35 | ≤0.5 | ≤0.5 |
Cu | ≤0.5 | ≤1 | -- | -- | ≤0.5 | ≤0.3 | ≤0.5 | 1.5-3 |
Ni | ≥72 | 58-63 | ≥44.5 | Bal | ≥58 | 50-55 | ≥70 | 38-46 |
Co | -- | -- | 10-15 | ≤1.0 | -- | ≤1 | ≤1 | -- |
Al | -- | 1-1.7 | 0.8-1.5 | ≤0.4 | -- | 0.2-0.8 | 0.4-1 | ≤0.2 |
Ti | -- | -- | ≤0.6 | ≤0.4 | -- | -- | 2.25-2.75 | 0.6-1.2 |
Cr | 14-17 | 21-25 | 20-24 | 20-23 | 27-31 | 17-21 | 14-17 | 19.5-23.5 |
Nb+Ta | -- | -- | -- | 3.15-4.15 | -- | 4.75-5.5 | 0.7-1.2 | -- |
Mo | -- | -- | 8-10 | 8-10 | -- | 2.8-3.3 | -- | 2.5-3.5 |
B | -- | -- | ≤0.006 | -- | -- | -- | -- | -- |
SPECIFICATIONS | |
Form | ASTM |
Rod, bar and wire | B 166 |
Plate, sheet and strip | B 168, B 906 |
Seamless pipe and tube | B 167, B 829 |
Welded pipe | B 517, B775 |
Fitting | B 366 |
Billet and bar for reforging | B 472 |
Forging | B 564 |
Shape | Size (mm) |
Wire | 0.5-7.50 |
Rod/Bar | 8.0-200 |
Strip | (0.5-2.5)*(5-180) |
Tube/Pipe | Customized |
Sheet/Plate | Customized |
For more details, pls directly contact us.
Feature:
Corrosion resistance: Inconel sheets have excellent corrosion resistance, can resist the erosion of acidic, alkaline and oxidizing media, and can adapt to the corrosive environment in the chemical industry.
High-temperature stability: Inconel sheets can maintain mechanical properties and stability in high-temperature environments and are suitable for high-temperature chemical processes.
Strength and Toughness: Inconel sheets have excellent strength and toughness and are able to withstand the stress and impact loads found in the chemical industry.
Plasticity and processability: Inconel sheets have good plasticity and processability, and can be formed and processed according to chemical process requirements to meet the needs of complex equipment.
Application areas:
Chemical equipment: Inconel sheets are often used to manufacture corrosion-resistant parts of chemical equipment, such as reactors, distillation towers, pipelines and storage tanks.
Catalyst carrier: Inconel sheets are widely used to manufacture catalyst carriers for catalytic reaction processes in the chemical industry.
Petroleum Refining: Inconel sheets are used in the petroleum refining process to manufacture corrosion-resistant pipes, heat exchangers and reactors to handle corrosive media and high temperature conditions.
Q&A:
What are the main advantages of Inconel sheets in the chemical industry?
The main advantages of Inconel sheet in the chemical industry are its excellent corrosion resistance and high temperature stability. This enables it to operate stably for a long time in corrosive media and high temperature environments, extending the service life of the equipment.
What are the specific applications of Inconel sheets in chemical equipment?
Inconel sheets are widely used in chemical equipment to manufacture corrosion-resistant components, such as reactors, distillation towers, pipelines and storage tanks. It can resist the corrosive attack of chemicals and ensure the reliability and safe operation of equipment.
What are the advantages of Inconel sheets compared with other materials in the chemical industry?
Compared with other materials, Inconel sheets have higher corrosion resistance and high temperature stability in the chemical industry. It can withstand chemical corrosive media and high-temperature environments, and has good plasticity and processability to meet the requirements of complex equipment.
